GIBAIR – PIPE TRANSFER SYSTEM FOR FOOD PRODUCTS
GIBAIR PNEUMATIC CONVEYING SYSTEM WITH SONIC EFFECT FOR SOLID AND LIQUID FOOD PRODUCTS
Le GIBAIR product is a pneumatic transport system. It was specially designed for transfer large volumes of product or co-product by piping.
Our company GMMI is world leader in long-distance transfer to slaughterhouses and the food industry (turkey, broilers, ducks, powders, cattle, pork, fish).
We know that the handling and transportation of products or by-products can be a source of problems for slaughterhouses, especially over long distances. We have an answer adapted to your needs for your application.
- Hard materials.
- Soft materials.
- Powdery materials.
- Granular materials.
- Viscous materials.
- Creamy materials.
- Pasty materials.
- Plastics and deformable packaging.
GIBAIR patented pneumatic conveying system
Biosecurity: hygiene, safety and reliability
Option: automatic cleaning
Pressurized air: actuator pressure 6 bars minimum
- GIBAIR 150 AIR 80 – Maximum flow of soft materials: 4 m3 / Hour.
- GIBAIR 150 SL / STD 80 – Maximum flow rate for soft and hard materials: 4 m3 / Hour.
- GIBAIR 200 SL / STD 100 – Maximum flow rate for soft and hard materials: 4 m3 / Hour.
- GIBAIR 300 SL 100 – Maximum hard material flow: 3 to 5 m3 / Hour and soft materials: 7 m3 / Hour.
- GIBAIR 300 SL / STD 125 – Maximum hard material flow rate: 3 to 8 m3 / Hour and soft materials: 13 m3 / Hour.
- GIBAIR 450 SL 200 – Maximum hard material flow: 3 to 8 m3 / Hour and soft materials: 15 m3 / Hour.
GIBAIR TECHNICAL SHEET
| PRODUIT GIBAIR | ||||
|---|---|---|---|---|
| 4 x less energy 7 x more powerful 2 x quieter than vacuum vacuum technology |  |  |  |  |
| Ø inlet / Ø outlet | GIBAIR 150/80 | GIBAIR 200/100 | GIBAIR 300/125 | GIBAIR 300/200 |
| Ejection capacity | 0.5 to 5 m³ / h (1) | 2 to 4 m³ / h (1) | 2 to 10 m³ / h (1) | 2 to 11 m³ / h (1) |
| Air storage cylinder | 30L | 45L | 2 x 45L | 2 x 45L |
| Electric tension | 400 V-TRI + T 4 A min | 400 V-TRI + T 4 A min | 400 V-TRI + T 4 A min | 400 V-TRI + T 4 A min |
| Cleaning in place (CIP - CIP) | Optional | Optional | Optional | Optional |
| Pre-equipped box | Yes | Yes | Yes | Yes |
| soundproof | Yes | Yes | Yes | Yes |
| Dimensions (W x H x D) in mm | 858 x 500 x 1345 | 700 x 712 x 1150 | 1320 x 875 x 1355 | 1355 x 890 x 1440 |
| Distance and height (with intermediate trigger) | ∞ | ∞ | ∞ | ∞ |
| Application examples | ||||
| Chicken, turkey, duck | GIBAIR 100 | GIBAIR 200 | GIBAIR 300 | |
| Viscera, Neck, Liver / heart / gizzard, Rump | Head, Leg, Viscera, Loin, Neck, Liver / heart / gizzard, Drumstick, Rump, Wing tip | VSM, Carcass, Seized, Head, Leg, Viscera, Echin, Neck, Bone, Skin, Liver / heart / gizzard, Drumstick, Rump, Wing tip | ||
| Powder, granulated | GIBAIR 150 | GIBAIR 200 | GIBAIR 300 | |
| Sec | Dry, fatty | Dry, fatty | ||
| Cattle | GIBAIR 150 | GIBAIR 200 | GIBAIR 300 | |
| - | - | Tallow, viscera, suppressant | ||
| Hog | GIBAIR 150 | GIBAIR 200 | GIBAIR 300 | |
| - | Viscera, suppressant | Suppressant, tallow, viscera | ||
| Fish | GIBAIR 150 | GIBAIR 200 | GIBAIR 300 | |
| Bone, head, viscera, whole fish | Bone, head, viscera, whole fish | Bone, head, viscera, whole fish | ||
